GT 100Râ„¢

Standard features

• 1000 lbs (454 kg) Capacity
• 1:2 Cable Hydraulic Drive System
• 30 fpm (0,15 m/sec)
• 3 HP Motor
• 220V / 1ph / 60Hz.
• GT-EZ100R^TM Control with Tape reader
• Submersible Motor with Submersible Pump
  Unit GT-100SBPower^TM
• 10'' (254 mm) Pit Depth Only
• 96'' (2438 mm) Overhead
• Emergency Lowering Valve
• Two Way Levelling
• Emergency UPS Lowering Device
• Constant Pressure Operation
• Slack/Broken Cable Safety Device
• Emergency Stop Button with Alarm
• Down Speed Flow Control
• Low Pressure Switch Safety Device
• Emergency Pit Switch
• In Use Indicator

Standard cab features

• 6'-8'' (2032 mm Cab Height)
• Two (2) Standard Cab Wall Colors
• Stainless Steel #4 modular CAB shell
  wall reveals and bases
• Stainless Steel Satin Car Operating Panel
• Ceiling: Melamine Panel with 2 Pot Lights
• Plywood Flooring with Recess to
  allow Floor Finish by Others
• Stainless Steel Satin Handrail

Options

• Single Automatic Operation
• Reduced Pit and Overhead
• Alternate Cab Wall Colors
• Multi-Speed Valve
• Manual or Automatic Collapsible Car Gate
  GT-Woodfold^TM or GT-Visifold^TM
• Standard GT Door Frame and Hardware
• Automatic or Manual GT-Swingdoors^TM
• Custom Plastic Laminate or Custom Wood Interior Finishes
• Custom Stainless or Bronze Finishes
• Custom Size, Custom Design, Architectural Cab Interior
• Retiring Cam
• Electric Strike - PrudHomme
• Glass Cab & Glass Doors
• Phone Cabinet or Hands Free Phone
• Digital Position Indicator

• Fully Enclosed Residential Lift
• Full Cab - 6'-8'' (2032 mm) Height
• Up to 1000 lbs Capacity
• Heavy Duty Steel Construction
• Proven Reliability
• Broken Cable Safety
• All Safety Features Included
• Modern and Innovative Technology
• Easy to Install
• Outstanding Quality Performance
• Cantilevered System
• Low Maintenance
• Smooth & Quiet
• Microprocessor Control GT-EZ100R
• CSA Approved Components
