Residential elevator

Global Tardif is proud to introduce the unique GT SoftRideMC (Machine-Room-Less) lift system. GT SoftRideMC products incorporate the future generation of elevatoring technology and design providing the smoothest and quietest drive available in the accessibility market for any commercial or residential applications!

The virtually noiseless SF100Râ„¢ Series system consumes very low power primarily due to the utilization of an energy efficient ACVVVF permanent magnet gearless machine. Combined with our PLC programmable Control, the GT-Tektronik SRX 100â„¢, the SF100Râ„¢ Series leads the way in performance and value.

The GT SoftRideMC elevator is without a doubt the most economical and environmental friendly solution where hydraulic or chain drive systems have been traditionally tried. This streamlined advanced designed elevator system features exceptional performance and reliability.

Key features

• Instantaneous Safety Device
• GT-Tektronik SRX 100MC control
• Two Way Levelling Tape Reader Levelling System
• 8'' (205 mm) Pit Depth Only
• 100'' (2540 mm) Overhead
• GT-WoodfoldMC ou GT-VisifoldMC folding door
• Constant Pressure Operation
• Manoeuvre automatique simple
• Overspeed Governor
• Emergency Stop Button with Alarm
• Emergency Pit Switch
• In Use Indicator

Standard Cab Features

• 6'-8'' (2032 mm) Cab Height
• Two (2) Standard Cab Wall Colors
• Stainless Steel #4 modular CAB shell
  wall reveals and bases
• Stainless Steel Satin Car Operating Panel
• Ceiling : Melamine Panel with 2 Pot Lights
• Plywood Flooring with Recess to allow Floor Finish
• Stainless Steel Satin Tubular Handrail

Landing Entrances

• GAL Door Interlock - Type "N"
(Doors, Frames and Hardware Usually Supplied
by General Contractor)



ENERGY SAVINGS

• Energy Saving Up to 60% vs
  Conventional Hydraulic Lifts
• Low Power Consumption
• High Efficiency PM Motor Technology

RIDE QUALITY

• Gearless Traction Elevator Performance
• Extremely Smooth Ride
• Quiet, Virtually Noiseless Operation

ENVIRONMENTALLY RESPONSIBLE

• Environmentally Friendly
• No Hydraulic Oil - Zero Spill Risk
• No Hot Oil Smell

BUILDING EFFICIENCY

• Recover Machine Room Space
• Flexible Layout

MRL TECHNOLOGY

• Proven Reliability
• Universally Maintainable Design
• Standard Commercial Components

APPLICATIONS / FEATURES

• Heavy Duty Manufactured
• Upgraded Cab - Standard
• 1-Year Warranty
petite camera
Show the pictures galery
  Related infos
 • Planning Guide & drawings

 • Brochure

 • Specifications
    (Pdf)     (Word)

 • Cab Weight Chart

 • Melamines (Standard)

 • Plastic Laminates (Option)

 • Entrance Colors

 • 1 Year Warranty

 • Request for proposal
    (PDF)    (MS Excel)
