Traction elevators / Passenger type - Geared basement
Any size, any shape... We can go up to 30 000 lbs ! Please contact us to customize your project !
FRONT / FRONT & REAR OPENING
Capacity / speed | |||||||||||||||||||||||||||||||||||
Capacity (lbs) [Kg] | 2100 | 953 | 2500 | 1134 | 3000 | 1361 | 3500 | 1588 | 4000 | 1814 | |||||||||||||||||||||||||
Speed (fpm) [m/s] | 150 to 500 | 0.75 to 2.5 | 150 to 500 | 0.75 to 2.5 | 150 to 500 | 0.75 to 2.5 | 150 to 500 | 0.75 to 2.5 | 150 to 500 | 0.75 to 2.5 | |||||||||||||||||||||||||
Elev. Dim. (in) [mm] | |||||||||||||||||||||||||||||||||||
Platform width (PW) | 6'-0" | 1829 | 7'-0" | 2134 | 7'-0" | 2134 | 7'-0" | 2134 | 8'-0" | 2438 | |||||||||||||||||||||||||
Platform depth (PD) | 5'-1" | 1549 | 5'-1" | 1549 | 5'-7" | 1702 | 6'-3" | 1905 | 6'-3" | 1905 | |||||||||||||||||||||||||
Platform depth front / rear opening (PDR) | 5'-6 3/4" | 1695 | 5'-6 3/4" | 1695 | 6'-0 3/4" | 1848 | 6'-8 3/4" | 2051 | 6'-8 3/4" | 2051 | |||||||||||||||||||||||||
Clear opening (CO) | 3'-0" | 914 | 3'-6" | 1067 | 3'-6" | 1067 | 3'-6" | 1067 | 4'-0" | 1219 | |||||||||||||||||||||||||
Entrance Type | 1 Speed² or CO1,2 | 1 Speed² or CO1,2 | 1 Speed or CO² | 1 Speed or CO² | 1 Speed or CO² | 1 Speed or CO² | 1 Speed or CO³ | 1 Speed or CO³ | CO³ | CO³ | |||||||||||||||||||||||||
Hoistway (in) [mm] | |||||||||||||||||||||||||||||||||||
Hostway width (HW) | 7'-4" | 2235 | 8'-4" | 2540 | 8'-4" | 2540 | 8'-4" | 2540 | 9'-4" | 2845 | |||||||||||||||||||||||||
Hostway width front / rear opening (HWR)5 | 8'-5" | 2565 | 9'-5" | 2870 | 9'-5" | 2870 | 9'-5" | 2870 | 10'-5" | 3175 | |||||||||||||||||||||||||
Duplex hoistway (DHW)5,6 | 15'-0" | 4572 | 17'-0" | 5182 | 17'-0" | 5182 | 17'-0" | 5182 | 19'-0" | 5791 | |||||||||||||||||||||||||
Triplex hoistway (THW)5,6 | 17'-2" | 5232 | 19'-2" | 5842 | 19'-2" | 5842 | 19'-2" | 5842 | 21'-2" | 6452 | |||||||||||||||||||||||||
Hostway depth (HD)5 | 7'-0" | 2134 | 7'-0" | 2134 | 7'-6" | 2286 | 8'-2" | 2489 | 8'-2" | 2489 | |||||||||||||||||||||||||
Hostway depth front / rear opening (HDR) | 6'-7 1/4" | 2013 | 6'-7 1/4" | 2013 | 7'-1 1/4" | 2165 | 7'-9 1/4" | 2369 | 7'-9 1/4" | 2369 |
Minimum overhead dimension (min. OH)⁴ (Deflector sheave in machine room) | |||||||||||||||||||||||||||||||||||
Capacity (lbs) [Kg] | 2100 | 953 | 2500 | 1134 | 3000 | 1361 | 3500 | 1588 | 4000 | 1814 | |||||||||||||||||||||||||
150-200 [0.75-1.0] | 18'-6" | 5639 | 18'-6" | 5639 | 18'-6" | 5639 | 18'-6" | 5639 | 18'-6" | 5639 | |||||||||||||||||||||||||
250-350 [1.25-1.75] | 19'-4" | 5893 | 19'-4" | 5893 | 19'-4" | 5893 | 19'-4" | 5893 | 19'-4" | 5893 | |||||||||||||||||||||||||
400 [2.0] | 19'-9" | 6020 | 19'-4" | 6020 | 19'-9" | 6020 | 19'-9" | 6020 | 19'-9" | 6020 | |||||||||||||||||||||||||
450 [2.25] | 21'-0" | 6401 | 21'-0" | 6401 | 21'-0" | 6401 | 21'-0" | 6401 | 21'-0" | 6401 | |||||||||||||||||||||||||
500 [2.5] | 21'-0" | 6401 | 21'-0" | 6401 | 21'-0" | 6401 | 21'-0" | 6401 | 21'-0" | 6401 |
For seismic conditions zone 2 and greater add to dimension (in) [mm] | ||||||||||||||||||
Capacity (lbs) [Kg] | 2100 | 953 | 2500 | 1134 | 3000 | 1361 | 3500 | 1588 | 4000 | 1814 | ||||||||
Hoistway width (HW) | 4" | 102 | 4" | 102 | 4" | 102 | 4" | 102 | 4" | 102 | ||||||||
Hoisway depth (HD) | 2" | 51 | 2" | 51 | 2" | 51 | 2" | 51 | 2" | 51 | ||||||||
Hoistway width front / rear opening (HWR) | 4" | 102 | 4" | 102 | 4" | 102 | 4" | 102 | 4" | 102 |
Notes:
1. Denotes non-compliance with ADA.
2. Will not accomodate ambulatory requirements.
3. Only in province of Alberta will not accomodate ambulatory requirements.
4. Designed for 8'-0" [2438] high Cab. For 9'-0" [2743] high Cab, Overhead + 1'-0" [305], for 10'-0" [3048] high Cab, Overhead + 2'-0" [610].
5. When occupable space is below hoistway, counterweight safeties are required. Add 9.5" [241] to the hoistway size of counterweight location.
6. Dimensional data is in accordance with ASME A17.1 and CAN/CSA B44 elevator codes.
* Any size, any shape... we can go up to 30 000 lbs ! Please contact us to customize your project !
* WARNING * Do not use those dimensions for final construction purposes. Local Code or Code year application might require differents spacing and will affect those dimensions. Please contact us for confirmation.
