*• Capacity: 750 lbs (340 Kg)
• 7'-0" (2134 mm) high cab
• Pit depth of 15" (381 mm)
• 220V, 1 phase, 50 or 60Hz
• GT-Tektronik SRX 500™ control
• Two-speed door operator
• Car top inspection station
• Single automatic operation
• Tape reader leveling system
• Emergency alarm and stop buttons
• Emergency cab lighting
• Hands free phone
• Pad hooks
• Digital position indicator

*• Maximum travel: 23'-0''

• Minimum overhead: 123'' (3124 mm)

• Speed: 40 to 50 fpm(0.2 to 0.25 m/s)

• Stainless steel #4 modular CAB shell wall reveals and bases
• Plastic laminated panels (Color selection as per our
standard GT color chart
• Solid plastic laminated ceiling with 2 pot lights
• Stainless steel # 4 cab front return, strike column &
car doors
• Stainless steel # 4 handrails
• Stainless steel # 4 control panel with braille tactile plates
• Led illuminated car direction indicator

Standard GT EZ-Entrances™:

• Passenger type
• 1 ½ Hr UL/ ULC fire rated entrances assembly
• Sill mounted spring door closers
• Bolted frame - three pieces knock down
• Square profile design - 2'' jamb & head jamb face
• Stainless steel # 4 door finish
• Aluminum sills
• Braille jamb plate (stick-on type)
options

Advantages:

ENERGY SAVINGS
• Energy saving up to 60% vs
conventional hydraulic lifts
• Low power consumption
• High efficiency PM motor technology

RIDE QUALITY
• Gearless traction elevator performance
• Extremely smooth ride
• Quiet, virtually noiseless operation

ENVIRONMENTALLY RESPONSIBLE
• Environmentally friendly
• No hydraulic oil - zero spill risk
• No hot oil smell

BUILDING EFFICIENCY
• Recover machine room space
• Flexible layout

MRL TECHNOLOGY
• Proven reliability
• Universally maintainable design
• Standard commercial components

APPLICATIONS / FEATURES
• Heavy duty manufactured
• Upgraded cab - standard
• 1-Year warranty

• Emergency battery power backup system for
powered lowering and door operation in the event of
a building power failure
• Optional speed ( SF500R)
• Reduced pit
• GT-EchoCab - modular stainless steel #4 framing with:
- Melamine panels (SF500C & SF500R)
- Plastic laminated panels (SF500 LU/LA, SF500C, SF500R)
• Custom wood interior finishes
• Custom stainless or bronze finishes
• Custom size, custom design, architectural cab interior
• Glass cab & glass doors
• Protective pads
